Hand Lever Operated Lug Type Butterfly Valve - BL Series

AvailabilityIn Stock
CategoryButterfly Valves
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%

Hand Lever Operated Lug Type Butterfly Valve - BL Series Details

 Technical Data (All dimensions are in mm)


SizeAØDF/FØLGJHEFlange
50 MM17050431202041322511F05
65 MM19265461402261222511F05
80 MM2198046152.52521422511F05
100 MM25810052190.52891726014F07
125 MM287125562163202026017F07
150 MM318150562413531926017F07
200 MM393200602984312229022F10
250 MM465250683625052529022F10

Specifications

End Connection:

Lug

Range:

DN50 - DN300

Suitable to:

ASMI B16.5 150#

Pressure Range:

PN06,PN10, PN16

Leakage Class:

100% Tightness at fully differential pressure

Standard:

API 609, BS 5155, ISO 5211, API 598, ASME B16.5

Body Material:

Cast Iron(CI), SGI, WCB, CF8, CF8M

Disc Material:

SGI, CF8, CF8M, WCB

Stem Material:

SS410, SS304, SS316

Body Liner / Seat Material:

NBR, EPDM, VITON, SILICONE

Shaft Bearing Material:

PTFE

Diaphragm & Media Temp:

PTFE

RPTFE

CFT

GFT

-30°C to 200°C

-30°C to 200°C

-30°C to 200°C

-30°C to 180°C
