Uflow 3/2 Way Direct Acting Valve (NC / NO) - DAS Series
Call Now
WhatsApp
AvailabilityIn Stock
CategoryDirect Acting Valve
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%
Uflow 3/2 Way Direct Acting Valve (NC / NO) - DAS Series Details
Valve Information
- Port: Refer to the technical data sheet (Available BSP / NPT)
- End Connection: Screwed
- Body Material: SS ASTM A351 Grade 304 / 316, Brass Bar, Aluminum
- Media Temp & seal o-ring:
Nitrile(NBR) EPDM Viton(FKM) Silicone -30°C to 90°C -10°C to 140°C -10°C to 180°C -10°C to 60°C - Circumstance Temp: -10° C to 70° C
- Media: Air, Chemical, Gas, Oil, Steam, Hot Water, Oil.
- Main Features: Internal Parts are in superior corrosion-resistant steel (Equivalent to SS316L).Suitable for Food Industries, Pharmaceuticals, Chemical applications, & Highly corrosive environments.
- Operating Voltage & Power Consumption:
24AC 110AC 230AC 12DC 24DC 9W 9W 9W 10W 11W - Optional Feature: 90% Power saver series also available & Latching as per Application.
- Other Specification Data: Available on Request, Manually Override
Coil Information
- Coil Features: High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as required.
- Coil Housing: IP65 Epoxy square coil, IP65 Metallic round enclosure, IP67 Flameproof enclosure, IP68 Weatherproof enclosure
- Note: Use of a filter in the inlet port is recommended.
Technical Data
| Model No. | Body Material | Pipe (Inch) | Orifice (mm) | Min. Operating Pressure Kg/cm² | Max. Operating Pressure | Seal & 'O' Ring | Flow Factor Kv m³ / hr | ||
|---|---|---|---|---|---|---|---|---|---|
| NC | NO | NC | NO | ||||||
| DAS-TA119E025 | Aluminium | ¼” | 2.5 | - | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAS-TA104E015 | Aluminium | ¼” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAS-TA105E009 | Aluminium | ¼” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAS-TA111E009 | Aluminium | ¼” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAS-TA118E009 | Aluminium | ¼” | 0.9 | 0.9 | 0 | 40 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAS-TA104R1E015 | Aluminium | In : ¼”, Out : Namur | 1.5 | - | 0 | 10 | NBR / FKM / EPDM | 0.07 | -- |
| DAS-TA704E015 | Aluminium | ³⁄₈” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAS-TA204E015 | Aluminium | ½” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAS-TA205E009 | Aluminium | ½” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB004E015 | Brass | ¹⁄₈” | 1.5 | NA | 0 | 10 | NBR / FKM / EPDM | 0.07 | -- |
| DAC-TB119E025 | Brass | ¼” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-TB104E020 | Brass | ¼” | 2 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.11 | 0.07 |
| DAC-TB105E009 | Brass | ¼” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB111E009 | Brass | ¼” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB118E009 | Brass | ¼” | 0.9 | 0.9 | 0 | 40 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB719E025 | Brass | ³⁄₈” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-TB704E015 | Brass | ³⁄₈” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAC-TB705E009 | Brass | ³⁄₈” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB711E009 | Brass | ³⁄₈” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB219E025 | Brass | ½” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-TB204E015 | Brass | ½” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAC-TB205E009 | Brass | ½” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB211E009 | Brass | ½” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-TB218E009 | Brass | ½” | 0.9 | 0.9 | 0 | 40 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T119E025 | SS304 | ¼” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-T104E015 | SS304 | ¼” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAC-T105E009 | SS304 | ¼” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T118E009 | SS304 | ¼” | 0.9 | 0.9 | 0 | 40 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T111E009 | SS304 | ¼” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T719E025 | SS304 | ³⁄₈” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-T704E015 | SS304 | ³⁄₈” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAC-T705E009 | SS304 | ³⁄₈” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T711E009 | SS304 | ³⁄₈” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T219E025 | SS304 | ½” | 2.5 | NA | 0 | 5 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-T204E015 | SS304 | ½” | 1.5 | 1.5 | 0 | 10 | NBR / FKM / EPDM | 0.07 | 0.07 |
| DAC-T205E009 | SS304 | ½” | 0.9 | 0.9 | 0 | 16 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAC-T211E009 | SS304 | ½” | 0.9 | 0.9 | 0 | 25 | NBR / FKM / EPDM | 0.03 | 0.03 |
| DAS-TA104C012 | Aluminium | ¼” | 1.2 | NA | 0 | 10 | NBR / FKM / EPDM | 0.04 | -- |
| DAC-TB014C025 | Brass | ¹⁄₈” | 2.5 | NA | 0 | 3 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-TB004C012 | Brass | ¹⁄₈” | 1.2 | NA | 0 | 10 | NBR / FKM / EPDM | 0.04 | -- |
| DAC-TB104C012 | Brass | ¼” | 1.2 | NA | 0 | 10 | NBR / FKM / EPDM | 0.04 | -- |
| DAC-TB103C012 | Brass | ¼” | 1.2 | NA | 0 | 7 | NBR / FKM / EPDM | 0.04 | -- |
| DAC-TB114C025 | Brass | ¼” | 2.5 | NA | 0 | 3 | NBR / FKM / EPDM | 0.16 | -- |
| DAC-T103C016 | SS304 | ¼” | 1.6 | NA | 0 | 7 | NBR / FKM / EPDM | 0.07 | -- |
| DAC-T718E009 | SS304 | ³⁄8” | 0.9 | NA | 0 | 40 | NBR / FKM / EPDM | 0.03 | -- |
