Valve Information
Technical Data:Cylinder bore Ø (mm) | 32 | 40 | 50 | 63 | 80 | 100 |
Cushion stroke (mm) | 21 | 23 | 23 | 23 | 28 | 28 |
Standard strokes (mm) | 25, 50, 80, 100, 125, 160, 200, 250, 300, 320, 400, 500 |
Media: Compressed air - filtered - lubricated
Working pressure: 0.5 - 10 bar
Materials of Construction: Aluminum, Brass, Steel, Acetal, Polyurethane(Regular), Nitrile
Mountings: Foot Mounting, Front / Rear Flange, Male Clevis, Female Clevis,C enter Trunnion, Front Trunnion, Rear Trunnion
Accessories: Clevis Foot Bracket, Wall Mounting Bracket, Trunnion Bracket, Rod End Fork, Rod End Aligner, Rod End Spherical Eye
Ambient Temperature: -10°C to +70°C
