Type: | 3X2 |
Design: | Internal Pilot Operated Poppet Valve |
Port Size: | In / Out / Exhaust - 1/2" BSP (Available in NPT & BSPT) |
Media: | Compressed Air (Filtered & Lubricated) |
Working Pressure Range: | 05 to 50 Bar |
Orifice: | 18mm |
Flow Factor: | 5.3 CV |
Ambient/Medium Temperature: | -5°C to 60°C |
Materials of Construction: | Aluminium, Nitrile, PUR, Brass |
Coil Specification
Operating Voltage & Power Consumption: |
| ||||||
Coil Features: | High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as require. | ||||||
Coil Housing: | IP65 Epoxy square coil, IP65 Metallic round enclosure, IP67 Flameproof Junction box, IP68 Weatherproof enclosure. |
